ICPLW50LSMT&R
- Manufacturer: Isocom Components 2004 LTD
- Package: 6-SO Stretched
- Description: OPTOISO 5KV 2 CH TRANS S06
- RoHs Status:
Specifications
| Number of Channels | 1 |
| Output Type | Transistor |
| Input Type | DC |
| Current Transfer Ratio (Min) | 90% @ 3mA |
| Current Transfer Ratio (Max) | 200% @ 3mA |
| Current - Output / Channel | 8mA |
| Current - DC Forward (If) (Max) | 20 mA |
| Voltage - Isolation | 5000Vrms |
| Voltage - Output (Max) | 30V |
| Voltage - Forward (Vf) (Typ) | 1.4V |
| Turn On / Turn Off Time (Typ) | 300ns, 400ns |
| Operating Temperature | -40°C ~ 105°C |
| Package / Case | 6-SOIC (0.268", 6.80mm Width) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 6-SO Stretched |
| Product Status | Active |
| Rise / Fall Time (Typ) | - |
| Vce Saturation (Max) | - |
