SID1132KQ
- Manufacturer: Power Integrations
- Package: eSOP-R16B
- Description: 2.5A, 1200V REINFORCED ISOLATION
- RoHs Status:
Specifications
| Number of Channels | 1 |
| Pulse Width Distortion (Max) | - |
| Current - Output High, Low | 1.2A, 1.3A |
| Current - DC Forward (If) (Max) | - |
| Current - Peak Output | 2.5A |
| Voltage - Isolation | 5000Vrms |
| Voltage - Output Supply | 22V ~ 28V |
| Voltage - Forward (Vf) (Typ) | - |
| Technology | Magnetic Coupling |
| Approval Agency | - |
| Operating Temperature | -40°C ~ 125°C |
| Package / Case | 16-PowerSOIC (0.350", 8.89mm Width), 15 Leads |
| Mounting Type | Surface Mount |
| Common Mode Transient Immunity (Min) | 50kV/µs (Typ) |
| Supplier Device Package | eSOP-R16B |
| Propagation Delay tpLH / tpHL (Max) | 340ns, 330ns |
| Product Status | Active |
| Rise / Fall Time (Typ) | 450ns, 450ns |
